New Products |
|
|
 |
 Ultra-compact module size: 90x70x15 mm
Femtosecond pulse: Typical 400fs
Low repetition rate drift: <1kHz/degC
Stable polarization maintaining output |
|
|
|
 |
Bandpass bandwidth tuning range: 0.2nm to 10nm
Center wavelength tunning range: 1530 - 1570nm
Out-of-band suppression: > 40dB
In-band chromatic dispersion: <+/- 3 ps/nm
Flat-top sharp spectral edges
Low insertion loss and low PDL
Front-panel control and external control
Option for bi-directional operation |
|
|
|
|
 |
Bit rates from 39.8 - 44.0 Gb/s
Functions of 40 Gb/s Serial BERT
or 10Gb/s 4CH parallel BERT
40G data output pattern:
Quasi-PRBS (QPRBS) 27-1, 223-1, 231-1,
differential output 10G data output pattern:
PRBS 27-1, 223-1, 231-1, single ended output
20, 10, 2.5 and 0.6 GHz clock output for trigger
|
|
|
|
|
 |
1picosecond sampling resolution
Low sampling jitter : < 100 fs
Very high bandwidth : > 500 GHz
High signal sensitivity
Low polarization dependency
Software clock recovery without external clock
Real-time algorithm with fast refresh rate
Total bit-rate independent with tunable sampling rates
Data modulation format independent |
|
|
|
|
 |
Bandwidth variable from 0.2nm to 10nm
Center wavelength tunning range 1530 - 1570nm
Ideal flat-top filter response with sharp roll-off
Side-mode suppression of >40dB
Negligible chromatic dispersion within passband
Low insertion loss, low polarization sensitivity |
|
|
|
|
